General Information and Business Terms:
| Place of Origin | CHINA |
| Brand Name | ANBEN FIRE |
| Model Number | AB-RT |
| Certification | CE EN EN795:1996 |
| Minimum Order Quantity | 10 |
| Packaging Details | 1 PCS/BOX |
Quick Detail:
1200Pounds+20m
1800Pounds+30m
2600Pounds+40m
Aluminum Alloy
CE certificate
Description:
The rescue tripod is a retractable leg made of high-strength lightweight alloy. Its characteristics are that the safety factor is greater than 10, it is equipped with a self-locking device for rising and falling, and a special stainless steel wire rope has good flexibility and will not be damaged due to rust or lack of oil.
Applications:
Tripods are suitable for operations in high places, cliffs and confined spaces. Common confined spaces include various storage tanks, containers, reactors, railway tankers, ship cabins, sealed transportation channels, underground pipelines (such as cable trenches), flues, tunnels, grain Silos, pits, shafts, pulp tanks, sewage tanks, sewers, cellars, septic tanks, sewage wells, sewage channels, etc., are mostly non-conventional and non-continuous operations. Widely used in fire protection, municipal administration, and rescue agencies.
Specifications:
| Tripod Material | Aluminum alloy |
| Tripod Extension height | 2200cm |
| Tripod Shrink height | 1350cm |
| Transmission ratio | 5:1 |
| Winch specifications | 1200/1800/2600 pounds |
| Winch rope Length | 20/30/40 |
| Rope Diameter | 5mm |
| Rope Max Load | 2000kg |
| Weight | 34kg |
| Certificate | CE EN EN795:1996 |
Competitive Advantage:
It consists of a main body, a sling, a winch and an annular protection chain.
◆The retractable legs are made of high-strength lightweight alloy, with a safety factor greater than 10, and the bottom legs are equipped with annular protection chains;
◆The winch is equipped with a self-locking device for rising and falling, ensuring the safety of the sling;
◆The sling is made of special stainless steel wire rope, which has good flexibility and will not be damaged by corrosion or lack of oil;
◆Convenient assembly, it can be installed at the wellhead or pit mouth according to local conditions, and is not restricted by uneven ground. The retractable feet are made of high-strength lightweight alloy, with a safety factor greater than 10, and the feet are equipped with annular protection chains;
Tag:
Aluminum Alloy/CE/
